Opis
Bauger beli kupatilski radijator
BAUGER | 90/70/20 ˚C ΔT:60 ˚C | 80/60/20 ˚C ΔT:50 ˚C | 80/60/24 ˚C ΔT:46 ˚C | 80/60/26 ˚C ΔT:44 ˚C | 70/50/24 ˚C ΔT:36 ˚C | ||||||||
BELI | BELI | BELI | BELI | BELI | |||||||||
Dužina | Visina | Prečnik cevi | Broj cevi količina | Toplotna snaga | Toplotna snaga | Toplotna snaga | Toplotna snaga | Toplotna snaga | |||||
(mm) | (mm) | (mm) | Kcal/h | Watt | Kcal/h | Watt | Kcal/h | Watt | Kcal/h | Watt | Kcal/h | Watt | |
400 | 670 | 22 | 10 | 256 | 297 | 207 | 240 | 190 | 221 | 182 | 211 | 149 | 173 |
500 | 670 | 22 | 10 | 298 | 346 | 241 | 280 | 222 | 257 | 212 | 246 | 174 | 201 |
600 | 670 | 22 | 10 | 340 | 395 | 275 | 319 | 253 | 293 | 242 | 281 | 198 | 230 |
400 | 770 | 22 | 11 | 287 | 333 | 232 | 269 | 213 | 248 | 204 | 237 | 167 | 194 |
500 | 770 | 22 | 11 | 334 | 387 | 270 | 313 | 248 | 288 | 238 | 276 | 194 | 226 |
600 | 770 | 22 | 11 | 380 | 440 | 307 | 356 | 282 | 328 | 270 | 313 | 221 | 256 |
400 | 870 | 22 | 12 | 319 | 370 | 258 | 299 | 237 | 275 | 227 | 263 | 186 | 215 |
500 | 870 | 22 | 12 | 370 | 429 | 299 | 347 | 275 | 319 | 263 | 305 | 215 | 250 |
600 | 870 | 22 | 12 | 419 | 486 | 339 | 393 | 312 | 362 | 298 | 346 | 244 | 283 |
400 | 970 | 22 | 14 | 364 | 422 | 294 | 341 | 270 | 314 | 259 | 300 | 212 | 246 |
500 | 970 | 22 | 14 | 423 | 491 | 342 | 397 | 315 | 365 | 301 | 349 | 246 | 286 |
600 | 970 | 22 | 14 | 481 | 558 | 389 | 451 | 358 | 415 | 342 | 397 | 280 | 325 |
400 | 1050 | 22 | 16 | 406 | 471 | 328 | 380 | 302 | 350 | 289 | 335 | 236 | 274 |
500 | 1050 | 22 | 16 | 472 | 548 | 382 | 443 | 351 | 408 | 336 | 390 | 275 | 319 |
600 | 1050 | 22 | 16 | 540 | 627 | 437 | 507 | 402 | 466 | 385 | 446 | 315 | 365 |
400 | 1150 | 22 | 18 | 450 | 522 | 364 | 422 | 335 | 388 | 320 | 372 | 262 | 304 |
500 | 1150 | 22 | 18 | 526 | 610 | 425 | 493 | 391 | 454 | 374 | 434 | 306 | 355 |
600 | 1150 | 22 | 18 | 602 | 699 | 487 | 565 | 448 | 520 | 429 | 497 | 351 | 407 |
400 | 1400 | 22 | 22 | 549 | 637 | 444 | 515 | 408 | 474 | 391 | 453 | 320 | 371 |
500 | 1400 | 22 | 22 | 642 | 745 | 519 | 602 | 477 | 554 | 457 | 530 | 374 | 433 |
600 | 1400 | 22 | 22 | 735 | 852 | 594 | 689 | 546 | 634 | 523 | 606 | 428 | 496 |
400 | 1500 | 22 | 23 | 580 | 673 | 469 | 544 | 431 | 501 | 413 | 479 | 338 | 392 |
500 | 1500 | 22 | 23 | 677 | 785 | 547 | 635 | 503 | 584 | 481 | 558 | 394 | 457 |
600 | 1500 | 22 | 23 | 774 | 898 | 626 | 726 | 576 | 668 | 551 | 639 | 451 | 523 |
400 | 1600 | 22 | 24 | 611 | 709 | 494 | 573 | 454 | 527 | 435 | 504 | 356 | 413 |
500 | 1600 | 22 | 24 | 712 | 826 | 576 | 668 | 530 | 615 | 507 | 588 | 415 | 481 |
600 | 1600 | 22 | 24 | 814 | 944 | 658 | 763 | 605 | 702 | 579 | 672 | 474 | 550 |
400 | 1800 | 22 | 26 | 673 | 780 | 544 | 631 | 500 | 581 | 479 | 555 | 392 | 454 |
500 | 1800 | 22 | 26 | 783 | 908 | 633 | 734 | 582 | 676 | 557 | 646 | 456 | 529 |
600 | 1800 | 22 | 26 | 893 | 1036 | 722 | 838 | 664 | 771 | 635 | 737 | 520 | 603 |
